For Biochemical Analyzer
【Features】
- DIC's proprietary SS membrane contibutes high performance and low water vapor permeation
- Low pressure drop and compact size
- Because all the modules are inspected before shipment, initial failure rate is low and performance is guaranteed
- According to operation conditions, select a suitable module from a wide product portfolio
Bubbles in reagent and fluid sample have a negative impact on dispencing accuracy and optical measurement accuracy. It will prevent precise analysis. To improve analysis accuracy, degasification technology is essential.
EF Series（Small）
External Flow System(Small）
- Fluid directed outside of hollow fiber
【Features】
- Low pressure loss
- High-level degassing model
| Model | Flow Rate （Vacuum degree 2.7kPa） |
Dimensions | Pressure Resistance | Operating Temp. | Connection （Liquid） |
Connection （Vacuum） |
|
|---|---|---|---|---|---|---|---|
| Degassing Rate 80％ | Degassing Rate 50％ | ||||||
| EF-AG1SX | 6mL/min | 40mL/min | 68mm×φ24mm （2.68in×0.94in） |
0.2MPa （2bar, 29psi） |
5～45℃ （41～113°F） |
Lure fitting | Lure fitting |
| EF-MICRO EF-MICROX |
9mL/min | 60mL/min | 91mm×φ23.5mm （3.58in×φ0.93in） | Lure fitting | Lure fitting | ||
| EF-G2 EF-G2X |
50mL/min | 170mL/min | 115mm×φ30mm （4.53in×φ1.18in） |
Rc1/8 NPT1/8 female |
Rc1/8 NPT1/8 female |
||
| EF-AG2 EF-AG2X |
50mL/min | 170mL/min | 122mm×φ29mm （4.80in×φ1.14in） |
Lure fitting | Lure fitting | ||
| EF-G3 EF-G3X |
500mL/min | 1,200mL/min | 141mm×φ45mm （5.55in×φ1.77in） |
Rc1/8 NPT1/8 female |
Rc1/8 NPT1/8 female |
||
| EF-AG3 EF-AG3X |
500mL/min | 1,200mL/min | 159mm×φ42mm （6.25in×φ1.65in） |
Rc1/8 NPT1/8 female |
Rc1/8 NPT1/8 female |
||
| EF-G4 EF-G4X |
1,000mL/min | 2,000mL/min | 141mm×φ60mm （5.55in×φ2.36in） |
Rc1/4 NPT1/4 female |
Rc1/4 NPT1/4 female |
||
| EF-AG5 EF-AG5X |
1,000mL/min | 2,000mL/min | 151mm×φ54mm （5.94in×φ2.1in） |
Rc1/4 NPT1/4 female |
Rc1/4 NPT1/4 female |
||
- About Connection：
- It is possible to change a joint for a pillar, flange, etc. However, there are limitations for some products. Please inquire about specific products.
- About Flow Rate：
- They are just guidelines. Depending on liquid type and targeted degassing levels, you can use them beyond the guidelines.
- About Dimensions：
- Projected parts and connections are excluded. For details, please refer to product drawings.
